Automatic Infrared Bridge Cutting Machine Type ZLB

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1465780

• Place of Origin:

  China
• Automatic Infrared Bridge Cutting Machine Type ZLBS-400
  Introduction：
  The machine adopts advance automatic technologies of microcomputer controlling and automatic beam displacement orientation, the main components are imported, such as frequency converter, magnet ruler, laser marking lining instruments. so it is a combined multifunctional stone machine processing equipment with high precision ,steady performance, good applicability and high reliability. it is special for the cutting and processing of valuable ,big abnormal line ,which is the only most ideal synthetically stone cutting equipment in home at present.

  Parameter：
  Max. diameter of saw bit350mm- 500mm
  Dimensions of working platform 3200mm×2000mm
  Max. cutting size 3200mm×3200mm
  Cutting thickness 0～80mm
  Max. lifting travel of cutter 200mm
  Power of main motor 11kw
  Oil pump motor 2.2kw
  General power 15.8kw
  Water consumption 2m3/h
  Water pressure 0.2Mpa
  Gross weight 6200kg
  Machine dimension 5800mm×4700mm×2800mm
